How do you select and test a conformal coating that is right for your specific application? Or maybe you would like to create your own test specification due to any special characteristics of your device’s operating environment? Or depending on your geographical location, you may also be required to use a different testing specification that is dictated by local authorities.

A widely used method to create an internal specification, is to simply select a conformal coating material that meets an existing specification standard. Such standard could be MIL-I-46058C or IEC-60664. However, you must be careful to ensure that the existing standard that you choose, does indeed meet 100% of your requirements. In such cases, you may have to specify test methods from other existing standards.

 You can also read: Straightforward Explanation of the MIL-I-46058C Specification for Conformal Coatings

There are many standards, here a few common ones for your reference:

 Some standards are specific to a physical or mechanical property/attribute, such as adhesion or flammability. Others include a range of properties to test how well a conformal coating performs overall.

Here are some examples:

Note: These standards should be used for guidance only and the coating choice should be made based on your specific product requirements.

For example, for automotive applications you may need the following sequence:

1. Damp Heat, cyclic
2. Thermal cycle, -40°C to +130°C (read: Thermal Shock blog article)
3. Corrosive gas test
4. Damp heat constant
5. Salt Spray
6. Breakdown voltage
7. Coating adhesion
8. Vibration Testing

It is unlikely that all the tests that you require for your specific device already exist in one current test standard, however, the individual tests will probably exist embedded in current standards. To create your own targeted conformal coating test standard, you need to understand the device's operating environment demands and select the appropriate test from a range of existing international standards. You have now created a test standard specific to your device that meets international standards.

Qualified Products List (QPL)– There are only two standards that provide QPLs, MIL-I-46058C, and UL746E.   For all other desired test properties, internal lab testing must be performed. Successful completion will allow you to state that your product meets the standard.

You can also read: Conformal Coating Standards

At HumiSeal, we take quality and standards qualifications very seriously. Many of our materials are used in high-reliability and safety-critical applications globally. When selecting a HumiSeal conformal coating you can be sure that our products have been fully tested by independent sources and meet the required performance standards. Our technical support team is available to discuss your specific applications and advise.
